Input Voltage: 12 to 24Vdc (Fuse protection (3A) Polarity protection)
Input rated voltage: 24Vdc Rated POwer: 30 W I max.: 3.5A
Compatibility: All Raspberry Pi 2, 3, 4 & All Raspberry Pi B models
Communications & Accessories: RS-485, ICSP connector, I2C (3.3V), USB Type-C (Power Only),RTC, Raspberry Pi connectors
Power supply voltage: Screw terminal: 12 to 24Vdc USB terminal: 5Vdc
Power consumption: DC power supply: 20 W MIN.
Average input current: 0.5A
Insulation resistance: 20m? min.at 500Vdc between the AC terminals and the protective earth terminal.
Dielectric strenght: 2.300 VAC at 50/60 Hz for one minute with a leakage current of 10mA max. Between all the external AC terminals and the protective ground terminal.
Ambient temperature (operating): 0º to 60º C
Ambient humidity (operating): 10% to 90% (no condensation)
Ambient environment (operating): With no corrosive gas
Ambient temperature (storage): -20º to 60ºC
Raspberry Board: Raspberry Pi 4 B
I/O control method: Combination of the cyclic scan and immediate refresh processing methods.
Programming language: Linux applications: Bash Scripts, Python, C++, Node-Red and more!.
CPU: Broadcom BCM2711, Quad core Cortex-A72 (ARM v8) 64-bit SoC @ 1.5GHz
Website: https://www.raspberrypi.org/
